EN 54 Family Map: Which Part Applies to Each Fire Alarm Product?

A quick product-to-standard reference for fire detection and fire alarm systems

The essential distinction
EN 54 is not one universal product certificate. It is a family of parts addressing different products and functions. “EN 54 compliant” is therefore incomplete unless the applicable part, current edition/amendments, certificate scope and system compatibility are identified.

Quick map

Product / function	Primary EN 54 part(s)	Additional check
Control panel	EN 54-2	EN 54-4 for PSU; EN 54-13 for compatibility
Point detection	EN 54-5, -7, -10, -26, -29, -30, -31	Sensor technology and application environment
Special detection	EN 54-12, -20, -22, -27, -28	Beam, aspiration, line or duct application
Alarm notification	EN 54-3, -23, -24	Audible, visual or voice evacuation
MCP, isolator, I/O	EN 54-11, -17, -18	Panel and loop compatibility
Radio-linked component	EN 54-25 + functional product part	Radio link, battery and system compatibility
Important This document is a practical map, not the licensed standard text. Confirm the current edition, amendments, market status and harmonised/designated status from authoritative sources before specification, certification or procurement.

1. Core control and system components

EN 54	Scope	Typical application
EN 54-2	Control and indicating equipment	Kontrol ve gösterge donanımı (yangın alarm paneli)
EN 54-4	Power supply equipment	Güç kaynağı donanımı
EN 54-13	Compatibility and connectability assessment of system components	Sistem bileşenlerinin uyumluluğu ve bağlanabilirliği
EN 54-16	Voice alarm control and indicating equipment	Sesli alarm kontrol ve gösterge donanımı
EN 54-17	Short-circuit isolators	Kısa devre izolatörleri
EN 54-18	Input/output devices	Giriş/çıkış cihazları
EN 54-21	Alarm transmission and fault warning routing equipment	Alarm ve arıza uyarısı yönlendirme/iletim donanımı

Why EN 54-2 alone is not enough

EN 54-2 addresses control and indicating equipment. Power supplies, field devices, voice alarm functions, interfaces and system compatibility may fall under other parts. EN 54-13 is not a single product certificate, but rather a 'system certificate' indicating that the control panel and field devices have been tested and approved together by an independent testing institute. Procurement should therefore request both product-level evidence and system-level compatibility documentation.

Request during document checks

Certificate exactly matching the product name and model code
Standard part number, edition and if any changes.
Notified Body information and certificate scope
Declaration of Performance (DoP) and Notified Body approved CE marking as a legal requirement, if the relevant EN 54 standard is harmonised.
Compatibility list, user/installation manual and firmware limitations

Certificate ≠ system design

A product certificate does not automatically mean that the device's placement in the project or its cause-and-effect scenario is correct. Product conformity and the verification of project design, installation, and commissioning are separate layers.

2. Detection product map

EN 54	Product / function	Selection focus
EN 54-5	Point heat detectors	Confirm technology, classification, environment and certificate model scope
EN 54-7	Point smoke detectors using scattered/transmitted light or ionisation	Confirm technology, classification, environment and certificate model scope
EN 54-10	Point flame detectors	Confirm technology, classification, environment and certificate model scope
EN 54-12	Line detectors using an optical beam	Confirm technology, classification, environment and certificate model scope
EN 54-20	Aspirating smoke detectors	Confirm technology, classification, environment and certificate model scope
EN 54-22	Resettable line-type heat detectors	Confirm technology, classification, environment and certificate model scope
EN 54-26	Point carbon monoxide fire detectors	Confirm technology, classification, environment and certificate model scope
EN 54-27	Duct smoke detectors	Confirm technology, classification, environment and certificate model scope
EN 54-28	Non-resettable line-type heat detectors	Confirm technology, classification, environment and certificate model scope
EN 54-29	Multi-sensor fire detectors using smoke and heat sensors	Confirm technology, classification, environment and certificate model scope
EN 54-30	Multi-sensor fire detectors using carbon monoxide and heat sensors	Confirm technology, classification, environment and certificate model scope
EN 54-31	Multi-sensor detectors using smoke, carbon monoxide and optionally heat sensors	Confirm technology, classification, environment and certificate model scope

Three questions for correct mapping

• Which fire phenomenon is detected: smoke, heat, flame, carbon monoxide or a combination?

• Is detection point-type, line-type, duct-mounted or based on aspirating sampling?

• Does the certificate product description and model code exactly match the offered product?

Common error
Not every product called a “smoke detector” belongs under EN 54-7. Beam, aspirating, duct and multi-sensor devices may fall under different parts.

3. Alarm and connection products

EN 54	Product / function	Key note
EN 54-3	Sounder	Audible fire alarm notification
EN 54-11	Manual call point	Manual initiation of a fire alarm
EN 54-23	Visual alarm device	Coverage volume and mounting classification
EN 54-24	Voice alarm loudspeaker	Loudspeaker used in a voice alarm system
EN 54-25	Radio-linked component	Radio layer; does not replace the functional product part

How to read EN 54-25

For a wireless detector or alarm device, EN 54-25 may cover the radio link while another EN 54 part covers the detection or notification function. Verify that all relevant scopes match the exact product model.

4. Product evidence, system compatibility and design

Layer	Question to answer
Product standard	Does the product meet the performance requirements within its scope?
System compatibility	Do connected components operate safely and predictably together?
Design and installation	Is the correct product installed in the correct location and cause-and-effect scenario?
Maintenance and testing	Is continued performance demonstrated through tests and records?

EN 54-14 is different

EN 54-14 is guidance for planning, design, installation, commissioning, use and maintenance; it should not be presented as a product certificate. Apply it together with national rules, project requirements and competent-authority expectations.

5. Procurement checklist

• ☐ Product code and certificate model match exactly.

• ☐ Applicable EN 54 part matches the product function.

• ☐ Certificate scope, annexes, edition and amendments are verified.

• ☐ Declaration of Performance and marking are verified for the target market where applicable.

• ☐ Panel-device compatibility and supported firmware are documented.

• ☐ Environmental and mounting classifications suit the application.

• ☐ Cause-and-effect, power and battery calculations are updated.

• ☐ Commissioning tests, as-built documents and training are included.

6. Frequently asked questions

Is “EN 54 certified system” sufficient?

No. Identify the applicable part for each product, exact model scope and evidence of system compatibility.

Does an EN 54-2 panel certificate cover all connected devices?

No. Detectors, call points, sounders, isolators and modules have their own applicable parts and compatibility requirements.

Is EN 54-25 alone enough for a wireless detector?

Usually not. EN 54-25 addresses the radio link; the functional detection part should also be checked.

Is EN 54-14 a product certificate?

No. It is guidance for planning, design, installation, commissioning, use and maintenance.

Why confirm the standard again before publication?

Editions, amendments and harmonised/designated status can change, and target-market rules may differ.

Conclusion
Manage EN 54 conformity as an evidence chain: the right part, exact product model, current documents and demonstrated system compatibility. Finder quality and project teams can support product-document mapping and system architecture verification.
