FF MZ250 Intelligent Addressable Zone Module With Short Circuit Isolator

FEATURES

  • 1 conventional fire detection line input for connecting
     conventional devices
  • 1 formC relay output with potential-free contacts
  • Built-in short-circuit isolator
  • Occupies 2 addresses on the loop
  • Current-threshold based line monitoring
  • Extractable terminal blocks (loop and field side)
  • Compact ABS housing , installable in any environment type
  • Certified to EN 54-17 and EN 54-18
  • Made in Italy

Type 1 conventional
detection line
1 formC relay
Addresses Occupied on Loop 2
Loop Capacity Up to 240 addresses
Loop Voltage 27 VDC (average)
Average Current Consumption 130 µA
LED Current Consumption 6 mA (@ 27 VDC)
End of Line Resistor 2.74 kΩ
Dimensions 106 x 54 x 27 mm
Humidity 95% RH
