FF MIC250A-1/1C Intelligent Addressable 1 Input 1 Output Form C 1 Supervised Output Module With Short Circuit Isolator

FEATURES

• 1 supervised input channel for auxiliary device monitoring
• 1 formC relay output with potential-free contacts
• 1 monitored output with end-of-line and load power supervision
• Built-in short-circuit isolator
• Voltage reading at the terminals of the addressed device
• Three-colour status LED (red / green / yellow)
   controlled by the panel
• Monitored output supplied with end-of-line resistor
   and diode for fault detection
• Extractable terminal blocks (loop and field side)
• Compact ABS housing (matt white)
• Certified to EN 54-17 and EN 54-18
• Made in Italy
